Representing ViewModel events with StateFlow vs. SharedFlow vs. Channel

One of the most heated debates in the Android community is the use of StateFlow, SharedFlow, and Channel in the ViewModel. In this article, we will discuss the differences between these three, and suggest which one is the best for representing events.

StateFlow for events

Let's start from saying, that for most elements of the UI, StateFlow is undoubtedly the best choice. We can assume it is best for all the elements of our "state".

// Example of using StateFlow for state private val _exploreUiState = MutableStateFlow<ExploreUiState>(ExploreUiState.Loading) val exploreUiState: StateFlow<ExploreUiState> get() = _exploreUiState private val _genreUiState = MutableStateFlow<Resource<MovieGenre>>(Resource.Loading) val genreUiState: StateFlow<Resource<MovieGenre>> get() = _genreUiState private val _searchInputUiState = MutableStateFlow(SearchUiState()) val searchInputUiState: StateFlow<SearchUiState> get() = _searchInputUiState private val _sortAndFilterUiState = MutableStateFlow(SortAndFilterUiState()) val sortAndFilterUiState: StateFlow<SortAndFilterUiState> get() = _sortAndFilterUiState

However, it can be tricky when we use it for representing events, like showing a toast, navigation, or performing an action. Here we have a problem, as StateFlow is not designed for this purpose.

Let's consider using MutableStateFlow with a nullable value. It is null at start, and after an event is handled, so a non-null value can be seen as an event to handle.

// ViewModel private val _snackbar = MutableStateFlow<String?>(null) val snackbar: StateFlow<String?> get() = _snackbar // In case of error _snackbar.value = getMesssageFromError(error) // Fragment viewModel.snackbar.collect { message -> message?.let { showSnackbar(message) } viewModel.clearSnackbar() } // ViewModel function fun clearSnackbar() { _snackbar.value = null }

There are some problems though:

  • We need to remember to clear the state after handling the event, which makes this pattern a bit more complicated.
  • If two coroutines send two different events in a short period of time, one of those events might be lost. Especially if they have the same value, because MutableStateFlow ignores updates with the same value, but even different values can be lost if the second event is sent before the first one is handled, because StateFlow is conflated. So essentially, there are a few ways in which events can be lost.

Let's consider some other options now.

SharedFlow for events

In general, the best practice to represent events is to use SharedFlow. It is a much simpler abstraction that always emits value to all its current collectors.

// ViewModel private val _showSnackbar = MutableSharedFlow<String>() val showSnackbar: SharedFlow<String?> get() = _snackbar // In case of error _showSnackbar.emit(getMesssageFromError(error)) // Fragment viewModel.showSnackbar.collect { message -> showSnackbar(message) }

However, SharedFlow has a problem with view models, where UI can change, and in the meantime there is no observer. We deal with such a situation, for instance, when a user rotates the screen. If an event is sent during the rotation, it will be lost. I saw some people using a workaround for this problem: awaiting for the first observer to appear, and then sending the event. I like this solution, but I cannot guarantee that it is bulletproof, so I wouldn't use it for important events.

// ViewModel private val _showSnackbar = MutableSharedFlow<String>() val showSnackbar: SharedFlow<String?> get() = _snackbar // In case of error subscriptionCount.first { it > 0 } _showSnackbar.emit(getMesssageFromError(error)) // Fragment viewModel.showSnackbar.collect { message -> showSnackbar(message) }

The advantage of SharedFlow is that it is a simple, and it is the only solution that can be freely used by more than one observer.

Channel for events

The natural way of dealing with the aforementioned problem is using Channel with an unlimited capacity. It can be seen as a queue of events that are received by collectors. We can transform it into a Flow using receiveAsFlow function. If an event is sent when there is no observer, it will be received by the next observer.

// ViewModel private val _showSnackbar = Channel<String>(Channel.UNLIMITED) val showSnackbar = _showSnackbar.receiveAsFlow() // In case of error _showSnackbar.send(getMesssageFromError(error)) // Fragment viewModel.showSnackbar.collect { message -> showSnackbar(message) }

The problem of using a Channel is that there is a possibility that this event is lost, in an unlikely event of cancellation after sending the event, but before invoking its action (see this article and this issue).

The most important argument against using Channel is that it does not guarantee event delivery (that should not be a problem if we both send and receive events in Dispatchers.Main.immediate, what is quite often the case, as it is used by both viewModelScope and lifecycleScope, but always ensuring that is a fragile solution). That is why we should avoid this solution for events that are important for the user experience, like a transaction result. Such an event is better represented with StateFlow, that guarantees that the event will be delivered to the observer.

Turning events into state and using StateFlow

Time for the option, that I most often hear being recommended by Googlers. It is turning events into state, and using StateFlow for them. That is the only option I am sure is bulletproof, but my problem is that it is not the simplest one.

Let's consider an example of showing a snackbar. To represent it as a state, we would need to use a list of messages, show only the first one, and remove it after showing.

// ViewModel private val _snackbarQueue = MutableStateFlow<List<String>>(emptyList()) val snackbarQueue: StateFlow<List<String>> get() = _snackbar // In case of error _snackbarQueue.update { it + getMesssageFromError(error) } // Fragment viewModel.snackbar.collect { message -> if (message.isNotEmpty()) { val first = message.first() showSnackbar(first) viewModel.removeSnackbarMessage(first) } } // ViewModel function fun removeSnackbarMessage(message: String) { _snackbarQueue.update { it - message } }

It is probably possible that the same message will be shown twice, but not that it will be lost, which is preferable for important events.

A good argument behind this solution is that we do not need to learn intricacies of SharedFlow or Channel, we can just use StateFlow for everything, and develop patterns of using it for different purposes.

However, on the other hand, there is a good argument that events should be represented as events, and not as state (event happen, state is), and for that SharedFlow or Channel are better solutions (see this article).

Jetpack Compose

It is worth mentioning, that as much as a need for "events" was not that incommon in classic Android development, it is rather rare in Jetpack Compose. Many things, like dialogs, are not an event that needs to be sent to Android, but rather a state that decides what is now displayed on the screen. For representing that StateFlow is much more appropriate. Just remember to represent it appropriately, and consider, for instance, what should happen if you should show another dialog before the previous one is hidden.

// ViewModel private val _dialogQueue = MutableStateFlow<List<DialogData>>(emptyList()) val dialogQueue: StateFlow<List<String>> get() = _dialog // In case of error _dialogQueue.update { it + getDialogFromError(error) } // Jetpack Compose val dialogQueue = viewModel.dialogQueue.collectAsStateWithLifecycle() if (dialogQueue.isNotEmpty()) { val dialog = dialogQueue.first() AlertDialog(onDismissRequest = { viewModel.onDialogDismissed(dialog) }) { // ... } } // ViewModel function fun onDialogDismissed(dialog: DialogData) { _dialogQueue.update { it - dialog } }

Summary

I will not have a clear answer to the question of which one is the best, as from my point of view, for most cases it does not matter that much which one you choose. However, I do agree that for important events, it is safest to use StateFlow. Nevertheless, for most cases, I still see the advantage of using SharedFlow, for its possibility of having more than one observer, or Channel, for its simplicity. On the other hand, I wouldn't oppose if Google developers decided to standardize on using StateFlow for everything, as it might be easier and safer for those who are not familiar with SharedFlow or Channel. I also agree that if we use Jetpack Compose, representing everything as a state that needs to be reflected on the screen is the most appropriate.
